Building Own Block Cipher: Part 3 - AES
Building AES the IKEA Way: Follow the Manual or It Falls Apart
In the previous article
we built DES from scratch — not because it’s still relevant, but because it forces you to understand how block ciphers are assembled from specifications.
DES is awkward, bit-heavy, and full of historical baggage.
That’s exactly why it’s a good learning tool.
AES continues that journey — but with very different design goals and very different failure modes.
Where DES teaches structure,
AES teaches discipline.
Before touching code, let’s be honest about one thing:
AES is not interesting because it’s new.
It’s interesting because it’s everywhere.
Right now, AES is used in:
HTTPS (TLS)
Disk encryption (BitLocker, FileVault, LUKS)
Password managers
Cloud storage
Mobile devices
VPNs
Hardware security modules
If data is encrypted in 2025, there’s a very high chance AES is involved.
And yet, despite being studied, standardized, and deployed for more than 20 years, AES is still frequently implemented incorrectly.
Not because AES is broken.
But because people misunderstand what AES actually is.
AES Is Not Broken — Implementations Are
There are no practical cryptanalytic breaks of AES.
What does exist is a long history of failures caused by:
using AES-ECB (still happening)
reusing nonces in CTR or GCM
broken key expansion
incorrect byte/row/column layout
treating AES as “encryption” instead of a primitive
So the goal of this article is not to “learn AES”.
It’s to remove the illusion that AES is magic.
Scope of This Article (Read This First)
This article is an overview of how AES works and how it is implemented, based on a real, working implementation.
👉 The full implementation with detailed comments is here:
https://github.com/DmytroHuzz/build_own_block_cipher/blob/main/aes/aes.py
What you’ll find on GitHub:
full AES-128 implementation
key expansion
block encryption
CTR mode
tests against known vectors
What you’ll find here:
the mental model
the algorithmic structure
why the code is written the way it is
Think of this article as the assembly instructions
and the GitHub file as the assembled furniture.
Reading the AES Specification Like IKEA Instructions
AES is defined in FIPS-197: https://nvlpubs.nist.gov/nistpubs/fips/nist.fips.197.pdf.
The document is:
precise
clean
unforgiving
It is also extremely easy to think you understand while silently misreading it.
So I approached the spec the same way I approach IKEA manuals:
don’t assume understanding
follow the order literally
assemble exactly what is written
only then ask why it works
Before touching individual transformations, we need to understand the whole machine.
Step 0: The Big Picture — What AES Actually Does
Before key expansion, S-boxes, or finite fields, answer this:
What does AES look like as a complete algorithm?
AES in One Sentence
AES repeatedly transforms a 4×4 byte matrix (the state) using round-specific keys, until the original plaintext is no longer recognizable.
That’s it.
Everything else is detail.
The Three Moving Parts of AES
AES consists of exactly three conceptual components:
1. The State
16 bytes (128 bits)
arranged as a 4×4 matrix
transformed in place
2. The Round Keys
derived from the original key
one per round
injected using XOR
3. The Round Function
a fixed sequence of transformations
applied repeatedly
No branching.
No randomness.
No conditions.
AES is completely deterministic.
AES as a Loop (Not a Black Box)
For AES-128, the algorithm looks like this:
state = plaintext_block_as_state
round_keys = expand_key(key)
state ^= round_keys[0]
for round = 1..9:
SubBytes(state)
ShiftRows(state)
MixColumns(state)
state ^= round_keys[round]
SubBytes(state)
ShiftRows(state)
state ^= round_keys[10]
ciphertext = state_as_bytes
That’s the entire cipher.
If you understand this loop, every AES implementation becomes readable.
Why AES Starts with AddRoundKey
AES begins with AddRoundKey, before any substitutions or mixing.
This is deliberate.
It ensures:
the key affects the cipher immediately
no “raw plaintext” enters a round
every transformation is key-dependent
This is one of those design choices that looks boring — and turns out to be essential.
Why the Final Round Is Different
The final round does not include MixColumns.
Why?
Because MixColumns exists to:
spread changes across columns
increase diffusion between rounds
After the final round, there is no next round.
Removing MixColumns:
simplifies decryption
keeps symmetry clean
avoids unnecessary diffusion
AES isn’t symmetric by accident.
It’s symmetric because it was engineered to be implemented correctly.
AES Is Not “Encryption” Yet
At this point we have:
a block algorithm
deterministic output
no randomness
That means:
AES alone does not encrypt messages.
It encrypts one 16-byte block.
This is why modes of operation exist — something we’ll come back to later, especially since the implementation includes CTR mode.
Step 1: Key Expansion (Before Anything Else)
Before AES can encrypt anything, it expands the key.
This is not optional.
This is not a helper.
This is half the cipher.
Why Key Expansion Matters
AES does not reuse the same key every round.
Instead:
the original key is expanded into round keys
each round uses a different key
each round key depends on all previous ones
This prevents:
simple patterns
slide attacks
related-key attacks
What Key Expansion Actually Does
High-level process:
Split the key into 4-byte words
For every new word:
rotate
apply SubBytes
XOR with round constant (Rcon)
XOR with the word 4 positions back
The implementation mirrors the spec line-by-line — and that’s exactly what you want here.
This is not a place to be clever.
This is a place to be correct.
AddRoundKey: The Most Honest Operation in AES
Now that we have round keys, AES begins with AddRoundKey.
It’s simply:
XOR the state with the round key
Why XOR?
reversible
fast
symmetric
no information loss
AddRoundKey is how key material enters the cipher.
Everything else rearranges or mixes data —
this is where the key actually does something.
The AES State (Where Most Bugs Are Born)
AES operates on 16 bytes, arranged into a 4×4 matrix.
And this is where implementations silently fail.
The state is column-major, not row-major.
[ b0 b4 b8 b12 ]
[ b1 b5 b9 b13 ]
[ b2 b6 b10 b14 ]
[ b3 b7 b11 b15 ]
Your block_to_state and state_to_bytes functions make this explicit.
If this mapping is wrong:
AES still runs
output still looks random
tests almost pass
This is why AES bugs are dangerous.
SubBytes: The Only Non-Linear Step
SubBytes replaces each byte using a fixed lookup table (S-box).
Important fact:
This is the only non-linear operation in AES.
Everything else is linear algebra and XOR.
You can derive the S-box mathematically.
You don’t need to to implement AES.
Using the fixed table is correct and intentional.
ShiftRows: Small Function, Big Consequences
Each row is rotated left:
row 0 → 0
row 1 → 1
row 2 → 2
row 3 → 3
This step:
breaks column alignment
ensures diffusion across rounds
If your state layout is wrong, this is where everything collapses.
MixColumns: Algebra Without Fear
MixColumns treats each column independently.
It mixes bytes using fixed coefficients in GF(2⁸).
In practice:
multiplication by 2 → xtime
multiplication by 3 → xtime(x) XOR x
addition → XOR
reduction → fixed polynomial
The implementation strips this down to what actually matters.
No matrices.
No abstractions.
Just mechanics.
AES Rounds (Putting It Together)
AES-128:
initial AddRoundKey
9 full rounds:
SubBytes
ShiftRows
MixColumns
AddRoundKey
final round (no MixColumns)
At this point:
nothing is hidden
nothing is magical
everything is mechanical
That’s exactly what you want in cryptography.
CTR Mode: Turning AES into Real Encryption
Important clarification:
AES itself is not encryption.
It’s a block cipher.
To encrypt real data, we need a mode of operation.
Your implementation includes CTR (Counter) mode — deliberately.
How CTR Mode Works
CTR turns AES into a stream cipher:
Combine nonce + counter
Encrypt with AES
XOR with plaintext
Increment counter
Repeat
Key properties:
no padding
encryption == decryption
parallelizable
fast
Critical rule:
Never reuse the same key + nonce pair.
CTR is secure only if nonces are unique.
What AES Actually Teaches
DES taught structure.
AES teaches discipline.
Most AES failures are not cryptographic.
They are:
layout mistakes
key handling errors
mode misuse
overconfidence
Implementing AES once forces you to:
respect specifications
respect data layout
respect boring correctness
Summary
If you’ve made it this far —
you’re no longer “using AES”.
You’re implementing it.
And that changes how you read every crypto API forever.
